Details
Parameters
Color of emission
Blue (450-480 nm)
Electrical power
3.2
W
High
Brightness
ΦV
58.2
lm
IV
37.4
cd
ΦE
1100
mW
IE
706
mW/sr
ΦP
4.24
µmol/s
Beam angle
∢
80
°
Operating temperature
Top
min.
-40
°C
Top
max.
150
°C
Dimension
l
4.4
mm
w
4.4
mm
h
2.7
mm
Ordering codes
Downloads
Datasheets
Datasheet
Application note
General information
General information
General information
General information
Handling recommendations
Handling recommendations
Handling recommendations
Thermal management
Thermal management
Thermal management
Electrical design
Electrical design
Electrical design
